Spikes Tactical Upper 5.56 / 223 16" M4 LE 9" BAR2 Rail

OUT OF STOCK - $

Spikes Tactical Upper 5.56 / 223 16" M4 LE 9" BAR2 Rail

Price : $


  • Brand: Spike's Tactical
  • Model: STU5025-R9S
  • UPC: 815648021085
  • Availability: Out Of Stock
The Spike's Tactical ST-15 LE upper line-up is designed as a fully Mil-spec compliant upper series for law enforcement. This same level of quality and performance is now available to everyone, all at a price range that is affordable to shooters of any budget. Each component is manufactured to Mil-spec standards and backed by the Spike's Tactical Lifetime Warranty.

Feature Overview

  • Spike's Tactical 16", 1:7 Twist, Mil-spec Barrel
  • M4 Barrel Profile, Carbine Length Gas System
  • ST Micro Gas Block, .750" Diameter Gas Seat
  • Spike's Tactical Mil-spec M16 Bolt Carrier Group
  • ST BAR Rail System
  • A2 Flash Hider
  • Spike's Tactical Lifetime Warranty

Upper Specs Spike's Tactical M4 Flat Top Upper Receiver

  • CNC Machined from a 7075 T6 MIL-H-6088 Forging
  • Extended M4 Feed Ramps Machined before Plating
  • Mil-Spec 1913 Picatinny Rail
  • MIL-A-8625F Type III Class 2 Hardcoat Anodized Finish
  • Laser Engraved T-markings
  • Laser Engraved ST Spider logo
  • Interior MIL-L-46010 Dryfilm Lube
  • Mil-Spec Ejection Port Door Assembly with 5.3.1.2 MIL-STD-171 Phosphate Finish
  • Mil-Spec Forward Assist Assembly with Tool Steel Pawl and 5.3.1.2 MIL-STD-171 Phosphate Coating
  • Forged Mil-Spec Charging Handle with MIL-A-8625F Type III Class 2 Hardcoat Anodized Finish

Barrel Group

  • Barrel Steel is Certified MIL-B-11595E Chromoly Vanadium Alloy
  • Raw Barrel Steel is Magnetic Particle Inspected
  • Barrels are Stress Relieved
  • Mil-Spec M4 Barrel Extension with 5.3.1.2 MIL-STD-171 Phosphate Finish
  • 1.2.2.2 MIL-STD-171 Hard Chrome Chamber
  • 1.2.2.2 MIL-STD-171 Hard Chrome Bore
  • 5.56mm Nato chamber
  • All Chambers are Individually Checked for Head Spacing Before and After Plating
  • All Barrels are Individually High Pressure Tested (HPT) and then Individually Magnetic Particle Inspected (MPI)
  • 5.3.1.2 MIL-STD-171 Phosphate Finish on the Barrel Exterior, Including under the Front Sight Base
  • 1/2x28 Thread Pitch
  • Threads are Cut Concentric to the Bore
  • Gas Block or FSB is Pinned to the Barrel and Vertically Aligned
  • Rubber Coated Front Sling Loop
  • Mil-Spec 303 Stainless Steel Gas Tube enhanced with Melonite Finish
  • Muzzle Devices are Properly Timed and installed with Crush Washer

Fore End Group

  • Spike's Tactical BAR Rail System
  • CNC Machined from 6061 Extrusion with MIL-A-8625F Type III Class 2 Hardcoat Anodized Finish
  • Steel ST BAR Barrel Nut with 5.3.1.2 MIL-STD-171 Phosphate Coating
  • Featuring 5 QD Swivel Sockets for multi-fuction sling attachment
  • Wide Body design accommodates counter sunk suppressor bodies up to 1.6" in diameter

Bolt Carrier Group

  • Mil-Spec 8620 Tool Steel M16 Bolt Carrier with Shrouded Firing Pin
  • Carrier is 5.3.1.2 MIL-STD-171 Phosphate Coated inside and out with 1.2.2.2 MIL-STD-171 Hard Chrome Bore
  • Laser Engraved with ST Spider Logo
  • Mil-Spec Tool Steel Carrier Key
  • Carrier Key is 5.3.1.2 MIL-STD-171 Phosphate Coated inside and out with 1.2.2.2 MIL-STD-171 Hard Chrome Bore
  • Carrier Key is installed with Grade 8 Hardware and Properly Staked
  • Bolt is CNC Machined from Carpenter-158 Steel
  • Bolt is 5.3.1.2 MIL-STD-171 Phosphate Coated inside and out
  • All Bolts are Shot Peened per current Mil-Spec Requirements
  • All Bolts are Individually High Pressure Tested (HPT) and then Individually Magnetic Particle Inspected (MPI)
  • Tool steel Extractor is Shot Peened, 5.3.1.2 MIL-STD-171 Phosphate Coated, Fitted with a Mil-Spec Black Extractor Spring Insert and Mil-Spec Viton O-Ring
  • Mil-Spec Firing Pin with 1.2.2.2 MIL-STD-171 Hard Chrome Finish
  • Mil-Spec Cam Pin with 5.3.1.2 MIL-STD-171 Phosphate Coating
  • Mil-Spec Firing Pin Retaining Pin with 5.3.1.2 MIL-STD-171 Phosphate Coating
UPC 815648021085
MSRP $779.00
Accessories Four Rail Handguard and No Mags
Barrel Length 16
Barrel Lined Chrome Moly
Barrel Twist 1:7
Barrel Type 1:7
Bolt/Carrier Included Yes
Caliber .223 / 5.56
Caliber1 223 Rem
Caliber2 556NATO
Chamber 556
Finish / Color Black
Fit AR Rifles
Front Sights None
Gas System Direct Imp
Handguard Style Free Float Quad Rail
Manufacturer Part# STU5025-R9S
Model M4 BAR Upper
Notes Flat Top
Type AR15
Upper Reciever Style A4 Flat Top
Weight (Lbs) 6.3125
